45 Degree Flammability Tester Best Textile Testing Equipment For Quality Control In Fabrics

Ask Lasest Price
Brand Name :	YUYANG
Model Number :	YY054
Certification :	CE
Price :	pending
Payment Terms :	L/C, T/T
Supply Ability :	20
Delivery Time :	5

Add to Cart

Product Details
Company Profile

45 Degree Flammability Tester Best Textile Testing Equipment For Quality Control In Fabrics

Key attributes

place of origin

Guangdong, China

customized support

OEM, ODM

power

Electronic

brand name

YUYANG

model number

YY054

Product Name:

Textile Testing Equipment

Material:

Stainless Steel

Dimension:

580*410*860mm

Burner:

diameter 11mm ± 0.3mm

Weight:

40kg

Power Supply:

220V AC 50HZ

Packaging and delivery

Packaging Details

Plywood Box

Selling Units

Single item

Single package size

32.9X32.9X76.7 cm

Single gross weight

23.000 kg

45 Degree Automatic Flammability Tester

45 Degree Flammability Tester Best Textile Testing Equipment For Quality Control In Fabrics

Application

The 45-degree flammability tester for textiles is widely used in the textile industry, especially for testing the flammability of textiles when exposed to a heat source. This equipment is mainly used for fire safety testing of household textiles, industrial fabrics, fire-resistant clothing, and special textiles in industries such as aviation, construction, etc. With the continuous tightening of safety standards, the flammability testing of textiles has become an important part of compliance checks in many industries. The 45-degree flammability tester for textiles is not only applicable to manufacturers and testing institutions, but is also widely used in research institutions and laboratories for conducting research on the fire performance of related materials.

Standards

ASTM D 1230, ASTM F963, 16 CFR -1610, CALIF TB 117, CAN/CGSB 4.2 No 27.5, GB/T 14644

Parameters

Manual firing device, including sample holder and brushing device
Spread time scope: 0-99.99s
Firing time: 1s or specified
Resolution: 0.01s
Specimens clamp inside dimension: 152×38mm
Flame height: 15.875mm
Dimension: 540×410×300mm(L×W×H)
Igniter model: comply to ASTMD1230
Power Supply: 220V
Accessories: clamps 4pcs, weights, calibration plate 1pcs, Flame Gauge 1pcs

Features

Rotating cycle number can be pre-settable. Also, length of chain is adjustable
Inclined plane flammability tester stop automatically after getting the preset rotating cycles
45 degree flammability tester inclined flammability tester to ensure the testing accuracy and extend the service life, the nail hammer was made up of platinum steel

Detection functionThe testing function of the 45-degree flammability tester for textiles is extremely powerful and mainly includes the following aspects:
Flame spread rate detection
During the testing process, the equipment can accurately measure the time and distance it takes for the flame to spread from the ignition point of the sample to other parts. Based on this data, the spread rate of the textile in a fire can be evaluated, and thus the fire resistance performance can be analyzed.Sample combustion time measurementThe equipment will record the time from when the sample is ignited until it completely goes out. This data is crucial for evaluating the self-extinguishing properties and fire resistance of the material, especially for quality inspection during the production of fire-resistant clothing and household textiles.
Analysis of Flame and Smoke Generation QuantitiesThe equipment can analyze the height of the flames and the amount of smoke generated during the combustion process, helping to detect the flammability of materials and their impact on air quality. This function is particularly important when testing special materials, especially in high-risk applications.
Sample droplet behavior detectionBy observing and recording whether there is any melting and droplet phenomenon during the burning process of the sample, the equipment can detect whether there is a risk of burning substances drooping from the textile. This is particularly important for applications with high safety requirements (such as in the construction field).

What is the standard test method for the textile 45-degree flammability tester?The standard test method for the 45-degree flammability tester in textiles is usually carried out in accordance with the ASTM D1230 standard. During the test, the textile is exposed to a standard flame at a 45-degree angle, and the ignition time, burning time, and the residue left after burning are recorded. These data help to determine the flammability and fire resistance of the textile.

In which industries can I use this device?The 45-degree flammability tester for textiles is widely used in industries such as textiles, clothing, automotive interiors, and home upholstery. For industries that need to ensure that textiles meet strict fire safety standards, this equipment is an indispensable tool, especially for producing fire-resistant fabrics or products that need to comply with specific fire regulations.
